This shaft alignment tool is a portable laser instrument designed for aligning rotating shafts in industrial settings. It is intended for use where precise axial and angular positioning is required to reduce vibration and wear. The device is manufactured by SKF and comes as a Compact unit suited to field use by automation, electronics, electrical and mechanical professionals.
Features and Benefits
- Weighs 0.53 kg for easy single-person handling
Laser-based system for high-accuracy alignment outcomes
500mm measurement span enabling mid-range alignment tasks
Compact form supporting Rapid setup and transit between sites
Suitable for integration into routine maintenance procedures
Applications
- Suitable for aligning motor and pump shafts in production lines
Ideal for field maintenance in electrical drive systems
Used with rotating equipment in mechanical workshops
Can be used for corrective alignment during automation installs
How portable is the unit for frequent site visits?
The instrument’s low mass of 0.53 kg reduces operator fatigue and simplifies transport between service locations.
What measurement reach does it provide for shaft offset checks?
The system offers a 500mm laser span suitable for measuring and correcting mid-range misalignments.
Which manufacturer supplies this alignment equipment?
The device is produced by SKF, a recognised supplier of rotating-equipment tools.
Can this tool be applied across different industrial disciplines?
Its laser alignment method and handheld form factor make it applicable across automation, electronics, electrical and mechanical maintenance tasks.
Selection guidance
- Review the manufacturer specifications for compatibility with your equipment.
- Confirm the required dimensions and fitting arrangement before ordering.
- Check the intended operating conditions against the product documentation.
