Toshiba Air Conditioning RBC-TSI1 Interface Module 15VDC A+B Indoor BUS Network

Toshiba Air Conditioning RBC-TSI1 Interface Module 15VDC A+B Indoor BUS Network

Toshiba Air Conditioning RBC-TSI1 Interface Module 15VDC A+B Indoor BUS Network is listed for TieDex store sale under Toshiba Air Conditioning Remote Controllers. The brand/vendor is Toshiba Air Conditioning. This listing has been prepared with structured product information, clean import fields, image mapping, and SEO-ready content for online selling.

Product Overview

The Toshiba RBC-TSI1 is a cost-effective and versatile single-unit interface module designed to provide precise control and monitoring of a single Toshiba indoor air conditioning unit. With six configurable analogue inputs and compatibility with the 15VDC A+B indoor BUS network, the RBC-TSI1 offers a flexible solution for a wide range of applications including hotels, AHU systems, small commercial spaces and light-industrial environments. The unit supports both resistive and 0–10VDC input types, and can optionally be integrated with Modbus control via an RS-485 serial port for advanced building management connectivity. Why Choose the Toshiba RBC-TSI1 Interface?: The RBC-TSI1 provides an adaptable and reliable method for integrating Toshiba indoor units into controlled environments where sensor inputs, third-party triggers or specialist functions are required. With features such as ECO modes, grouped control, hotel room operation and AHU functionality, this compact interface offers installers

and system designers a powerful tool for tailoring performance and energy usage. Its ability to form and manage groups of up to 16 indoor units or 16 Air-to-Air heat exchangers further enhances its capability within distributed HVAC networks. Key Product Features: Direct BUS Network Connection: Integrates directly with the Toshiba 15VDC A+B indoor BUS network. Group Control Capability: Supports groups of up to 16 indoor units or 16 Air-to-Air heat exchangers. Six Programmable Analogue Inputs: Inputs configurable as resistive or 0–10VDC to suit a wide variety of sensors and control signals. ECO-1 Mode: Offers timed fan operation for improved energy management. ECO-2 Mode: Provides adjustable fan band control for further efficiency optimisation. Preset Mode Operation: Allows quick and repeatable configuration for common control scenarios. Hotel Room Operation: Supports functions tailored for guest-controlled comfort and energy-saving automation. Duty Standby Mode: Alternates

unit operation for extended equipment lifespan. AHU Mode: Enables integration with Air Handling Units for specialist ventilation setups. Optional Modbus Integration: RS-485 port available for Modbus control and BMS integration. Technical Specifications: Specification Details Model RBC-TSI1 Input Types Six analogue inputs (resistive or 0–10VDC) BUS Network Compatibility 15VDC A+B indoor BUS network Group Control Capacity Up to 16 indoor units or 16 Air-to-Air heat exchangers Operating Modes ECO-1, ECO-2, preset mode, duty standby, AHU mode Hotel Room Function Supported Communication Port RS-485 (optional Modbus control) Application Indoor unit monitoring and control interface

Key Details

• Brand / Vendor: Toshiba Air Conditioning
• Product SKU: Intensis RBC-TO-RC-WIFI-1-19624
• MPN / Model: Intensis RBC-TO-RC-WIFI-1
• Category: Toshiba Air Conditioning Remote Controllers
• Parent Category: Air Conditioning Remote Controllers Replacement
• Condition: New
• Availability: InStock
• TieDex UK
